600V XLPE cable UL3666 battery wire for energy storage system
▲Easy stripping and cutting
▲Good flexibility
▲High flamen retardant
▲High temperature resistance
▲UV resistant
Product Information:
Annealed soft tin copper
UL758
Conductor
Insulation
XLPE
Rated voltage
600V
Rated temperature
-40°C ~ +105°C
Reference Standard
Flame Test
UL VW-1
| Cable Name |
Cross Section (AWG) |
Construction (No./mm) |
Conductor O.D. (mm) |
Insulation thickness (mm) |
Insulation O.D. (mm) |
Conductor Resistance Max (Ώ/km,20°C) |
|
UL style 3666 |
26 | 7/0.16 | 0.48 | 0.38 | 1.30 | 150 |
| 24 |
11/0.16 |
0.61 |
0.38 |
1.45 |
94.2 | |
|
22 |
17/0.16 |
0.76 |
0.38 |
1.60 |
59.4 |
|
| 20 | 26/0.16 | 0.94 |
0.38 |
1.80 | 36.7 | |
| 18 | 16/0.254 | 1.15 |
0.38 |
2.00 | 23.2 | |
| 16 | 26/0.254 | 1.50 |
0.38 |
2.40 | 14.6 |
Application:
Company Profile:
CABLENTIS is a fast-growing solar company ,as well as a turnkey solution provider in China. Products cover PV modules, solar cables, half cut cell solar panel , solar pv mounting structure, fence, Mini inverter for home etc solar products .
CABLENTIS is committed to providing the best solutions for users, installers, investors and all stakeholders. We always take the responsibility on customer’s demands. We make our effort for innovations and breakthroughs.
FAQ:
Q: How could i get the sample ?
A: We have different kinds of XLPE insulation pv solar cable,photovoltaic cable,xlpe solar cable in stock, you can require for samples to check our quality.Samples are free provided, you only need to pay the courier fees.
Q: How long is the delivery time?
A1)For Sample: 1-3 Days;
A2)For small Orders: 3-10 Days;
A3)For mass Orders:15-20 Days;
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment or against B/L.
If you are an end users , we can offer more detail information to you.Please, if you have any questions or concerns about shipping time and delivery, you can ask our professional products consultant.
