TUV Certificate 62930 IEC131/H1Z2Z2-K 6mm2 DC waterproof Solar PV Cable
CABLENTIS waterproof photovoltaic cable, compliant with EN50618 & IEC6293 standard, passed DIN VDE0285-525221/DIN EN50525-2-21 AnnexE, AD7 Protection level against water ingress test, can be used in humid environments, with good waterproof effect.
Product description:
|
Voltage Rating(Uo/U) |
DC: 1500V |
Test Voltage |
6500V AC |
|
Temperature Rating |
Rated: -40°C to +90°C Max.conductor temp: +120°C |
Minimum Bending Radius |
fixed installation 5x outer Ø
|
|
Water Resistant |
DIN VDE0285-525221/DIN EN50525-2-21 AnnexE
|
Protection level against water ingress |
AD7 |
|
Cable Name |
Construction
(No./mm)
|
Inner Layer O.D.
(mm)
|
Outer Layer O.D.
(mm)
|
Conductor resistance
Max (Ώ/km)
|
|
62930 IEC131/ H1Z2Z2-K
|
78/0.295 |
4.45±0.10 |
6.10±0.15 |
13.7 |
Packing & Delivery:
Application Scenario:
Company Profile:
CABLENTIS is a fast-growing solar company ,as well as a turnkey solution provider in China. Products cover panel solar system, solar cables, solar extension cables , home energy solar systems, Solar power fence, three phase inverters etc solar products .
CABLENTIS is committed to providing the best solutions for users, installers, investors and all stakeholders. We always take the responsibility on customer’s demands. We make our effort for innovations and breakthroughs.
FAQ
Q: How could i get the sample ?
A: We have different kinds of XLPE insulation pv solar cable,photovoltaic cable,xlpe solar cable in stock, you can require for samples to check our quality.Samples are free provided, you only need to pay the courier fees.
Q: How long is the delivery time?
A1)For Sample: 1-3 Days;
A2)For small Orders: 3-10 Days;
A3)For mass Orders:15-20 Days;
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment or against B/L.
If you are an end users , we can offer more detail information to you.Please, if you have any questions or concerns about shipping time and delivery, you can ask our professional products consultant.
