NYY-J Solar Cable 1 Core 50mm² Direct Burial Wire
Power and control cable for fixed installation in the following applications: direct burial and building installation, fixed installation with various applications.
Product Description:
|
Conductor: |
Bare copper wire |
|
Core Insulation: |
PVC（*Filling compound over the core assembly） |
| Outer sheath: | PVC |
| Conductor stranding: | Single or multi-wire |
| Minimum bending radius: |
Single-core: 15 x outer diameter
Multi-core: 12 x outer diameter
|
| Nominal voltage: | U0/U: 0.6/1.0 kV |
|
Test voltage： |
4000V |
|
Protective conductor: |
J = with GN-YE protective conductor |
|
Temperature range: |
During installation: -5°C to +50°C Fixed installation: -40°C to +70°C |
|
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| 1x25 | 13 | 240 | 380 |
|
1x35 |
14 | 336 | 447 |
|
1x50 |
15 | 480 | 650 |
|
1x70 |
17 | 672 | 864 |
|
4x25 |
27 | 960 | 1620 |
|
5x25 |
29.9 | 1200 | 1920 |
Packing & Delivery:
Application Scenario:
Company Profile:
CABLENTIS is a fast-growing solar company, as well as a turnkey solution provider in China. Products cover panel solar systems, solar cables, solar extension cables, home energy solar systems, Solar power fences, three phase inverters etc solar products.CABLENTIS is committed to providing the best solutions for users, installers, investors, and all stakeholders. We always take responsibility for customers’ demands. We make our effort for innovations and breakthroughs.
